M12 S-CODE 5-Core Straight Pre Cast Connector - High Voltage Signal Transmission Expert
Product models: M1204SM-2/P00K/M1204SM-5/P00K/M1204SM-10/P00K
- ✓ 4-core power code, 12A high current carrying capacity
- ✓ IP67 waterproof and dustproof rating, suitable for harsh environments
- ✓ Gold plated contacts ensure stable signal transmission
- ✓ High flexibility PVC cable with long bending resistance and lifespan
Product advantages and features
Why choose KRONZ M12 S-CODE connector?
-
High voltage application expert
Support 630VAC high working voltage
5-core design meets complex signal transmission requirements
Excellent insulation performance, insulation resistance ≥ 100M Ω
-
Material and process advantages
Contact materials: alloy, copper zinc, gold plating
Connector nut: alloy, copper zinc, nickel plating
Contact carrier: PA black plastic, high temperature resistant
Clamping substrate: TPU black, high elasticity
-
Excellent environmental adaptability
IP67 protection level, completely dustproof and waterproof
Working temperature range: -25 ° C to+85 ° C
FPM/FKM sealing material, resistant to chemical corrosion
Pollution level 3, suitable for industrial environment
-
Reliable quality assurance
Contact resistance ≤ 5m Ω
Mechanical lifespan>100 insertions and removals
Compliant with international IEC standards
Factory direct sales, controllable quality
Product Overview
KRONZ M12 S-CODE 5-core straight pre cast connector is designed specifically for high-voltage industrial applications, supporting working voltages up to 630VAC. This product adopts a 5-core design and is suitable for devices such as sensors, encoders, motors, etc. that require multi signal transmission. Compliant with the IEC 61076-2-101 international standard, ensuring compatibility and reliability worldwide.
Core technical parameters
| Encoding Type |
S-CODE (High Voltage Encoding) |
| Pin quantity |
5 cores |
| Rated current |
12A |
| Working voltage |
630VAC |
| Cable specification |
5 × 1.5mm ² (5 × 16AWG) black PVC |
| Connector Type |
Straight Male/Female |
| Protection level |
IP67 |
| Optional length |
2M/5M/10M or customized |
Typical application areas
- High voltage sensor connection
- Encoder signal transmission
- Servo motor control
- Inverter connection
- Power monitoring system
- High voltage testing equipment
- Industrial automation production line
- new energy equipment
Ordering and Customization
Standard Model List
| model |
length |
Specifications |
| M1204SM-2/P00K |
2M |
4-core S-CODE straight type |
| M1204SM-5/P00K |
5M |
4-core S-CODE straight type |
| M1204SM-10/P00K |
10M |
4-core S-CODE straight type |
customized service
- Support customization of any length: 2M/5M/10M or any length
- Cable material options: P00K (PVC black)/P01K (PUR black)
- Code system: T-CODE/K-CODE/S-CODE/L-CODE/L-CODE
- Model: Straight or Curved
- Interface: Male/Female
- Wire gauge: PVC.PUR
- Pre cast wire color can be customized
- Customized production based on customer drawings or samples
- Provide professional technical consultation
Your Trusted Partner in Industrial Automation
KRONZ is a manufacturing enterprise located in Zengcheng District, Guangzhou, China. For many years, we have been dedicated to providing customers with efficient industrial automation solutions and related industrial products.
Core products: Industrial connectors,inductive/capacitive/optoelectronic/ultrasonic sensors, industrial power supplies, industrial fieldbus, RFID recognition systems, and industrial Ethernet switches.
R&D and production: We have complete product processing equipment and a professional team proficient in various automation technologies. In order to improve product quality and production efficiency, we continue to introduce advanced production equipment and technology, and constantly strengthen research and development investment.
Customization capability: We not only produce standard products, but also have strong customization production capabilities, which can produce according to customers' design drawings or samples.
Service philosophy: Adhering to the principle of mutual benefit and win-win, we provide customers with competitive prices and perfect after-sales service. KRONZ's products have been sold to multiple countries and have won the trust and praise of customers.
Secure Payment & Fast Shipping Worldwide
We provide flexible and convenient payment methods and a global logistics network to ensure the safety and fast delivery of your goods.
Payment Methods: We support various international payment methods such as PayPal, Western Union, T/T (telegraphic transfer),,etc. to ensure transaction security.
Shipping Partners: We maintain long-term partnerships with top logistics companies such as TNT, UPS, SF Express, FedEx, EMS, DHL, etc.
Transportation instructions:
Samples and small batch orders: We use fast shipping methods, including air freight and express delivery, to ensure that you receive the products for testing as soon as possible.
Large scale orders: You can choose sea freight, air freight, railway or truck transportation according to your needs, providing you with the most cost-effective logistics solution.
Proxy shipping: We can directly send the goods to your designated proxy warehouse.
Customized service: If you need special transportation methods, please feel free to contact us at any time.
Technical Support & Services
- Expert technical assistance for product selection and configuration
- Installation guidance and support
- Troubleshooting and issue resolution
- Product warranty and repair services
- Training and education resources
- Customized solutions for unique application needs
